Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 111
Installation and Wiring Chapter 6
Table 51 - Receiver Muting Plug-in DIP Switch Settings
Switch 450L-APR-MU-8 Description Comment
1OFF — —
2 OFF Low Range Disabled Optional
3 OFF Beam Coding Disabled Optional
4OFF — —
5OFF
Automatic Start
Optional
6OFF Optional
7 OFF EDM Disabled —
8ON Muting Required
9OFF or ON
DIP 9: OFF, DIP 10: ON, DIP 11: OFF 2L muting
DIP 9: ON, DIP 10: OFF, DIP 11: OFF 2T muting
Determines muting
type
10 OFF or ON
11 OFF
12 OFF — —
