Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 129
Chapter 9
Connected Components Workbench Software
Overview
The Connected Components Workbench software can be used to monitor the
450L light curtains and to configure the 450L-E version. The Bulletin 450L has
two versions:
• 450L-B: Basic ON/OFF
• 450L-E: Enhanced features
The Connected Components Workbench software can only monitor the 450L-B
version; the 450L-B does not have configurable parameters. The advantage of
450L-E safety light curtain is that Connected Components Workbench software
can monitor and configure it. Use the Connected Components Workbench
software to do the following:
•Setup
–Muting
– Floating blanking
–Reduced resolution
– Fixed blanking
– A combination of floating, reduced resolution, and fixed blanking
•Diagnostics
– Know which beams are blanked or blocked
–Review last 10 lockout codes
• Export the configuration to a file
The Connected Components Workbench software performs its function with
the 450L-OID Optical Interface Device (OID). For more information on the
OID, Optical Interface Device (OID) on page 120
.
Multiple Subconfigurations
This manual assumes that the Connected Components Workbench software,
Version 12 or later has been loaded.
