Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 195
Specifications Appendix A
Product Selection
Sticks
The catalog number refers to a stick, including top/bottom mounting kit and test
rod.
450L - B 4 H N - 0750 - Y D
abcd
abc d
Transceiver Stick
Type Resolution [mm (in.)] Laser Alignment Protected Height [mm (in.)]
Code Description Code Description Code Description Code Description Code Description
BBasic
H
Hand
(30 [1.19])
N
Not
integrated
0150 150 (5.91) 1200 1200 (47.28)
E Enhanced 0300 300 (11.82) 1350 1350 (53.19)
F
Finger
(14 [0.56]
LIntegrated 0450 450 (17.73) 1500 1500 (59.1)
0600 600 (23.64) 1650 1650 (65.01)
0750 750 (29.55) 1800 1800 (70.92)
0900 900 (35.46) 1950 1950 (76.83)
1050 1050 (41.37)
Protective Field
Length
[mm (in.)]
Cat. No.
(1)(2)
(1) Replace x with B for 450L-B or E for 450L-E.
(2) Replace y with N for 450L-B or with L for 450L-E.
Approximate
Shipping Weight
(With Packaging)
[kg (lb)]
Shipping
Dimensions
[mm (in.)]
Resolution
14 mm (0.56 in.)
Resolution
30 mm (1.19 in.)
150 (5.90)
450L-x4Fy0150YD 450L-x4Hy0150YD 0.59 (1.3)
860 x 111 x 68
(33.86 x 4.37 x 2.68)
300 (11.81)
450L-x4Fy0300YD 450L-x4Hy0300YD 0.72 (1.59)
860 x 111 x 68
(33.86 x 4.37 x 2.68)
450 (17.72)
450L-x4Fy0450YD 450L-x4Hy0450YD 0.85 (1.87)
860 x 111 x 68
(33.86 x 4.37 x 2.68)
600 (32.62)
450L-x4Fy0600YD 450L-x4Hy0600YD 0.98 (2.16)
1310 x 111 x 68
(51.57 x 4.37 x 2.68)
750 (29.53)
450L-x4Fy0750YD 450L-x4Hy0750YD 1.11 (2.45)
1310 x 111 x 68
(51.57 x 4.37 x 2.68)
900 (35.43)
450L-x4Fy0900YD 450L-x4Hy0900YD 1.24 (2.73)
1310 x 111 x 68
(51.57 x 4.37 x 2.68)
1050 (41.34)
450L-x4Fy1050YD 450L-x4Hy1050YD 1.37 (3.02)
1760 x 111 x 68
(69.29 x 4.37 x 2.68)
1200 (47.24)
450L-x4Fy1200YD 450L-x4Hy1200YD 1.5 (3.3)
1760 x 111 x 68
(69.29 x 4.37 x 2.68)
1350 (53.15)
450L-x4Fy1350YD 450L-x4Hy1350YD 1.63 (3.59)
1760 x 111 x 68
(69.29 x 4.37 x 2.68)
1500 (59.05)
450L-x4Fy1500YD 450L-x4Hy1500YD 1.77 (3.90)
2360 x 111 x 68
(92.91 x 4.37 x 2.68)
1650 (64.96)
450L-x4Fy1650YD 450L-x4Hy1650YD 1.91 (4.21)
2360 x 111 x 68
(92.91 x 4.37 x 2.68)
1800 (70.86)
450L-x4Fy1800YD 450L-x4Hy1800YD 2.05 (4.52)
2360 x 111 x 68
(92.91 x 4.37 x 2.68)
1950 (76.77)
450L-x4Fy1950YD 450L-x4Hy1950YD 2.18 (4.81)
2360 x 111 x 68
(92.91 x 4.37 x 2.68)
