Appendix A Specifications
General
Table 77 - General
Attribute Value
Materials Transceiver stick (450L-B…) or 450L-E:
• Profile: Extruded aluminum, powder coated
•End caps: Polyamide
• Front window: Polycarbonate
• Screws: Steel
Plug-in (450L-AP…):
• Pig tail cable: Polyurethane
• M12 Connector: Bare copper, SR-PVC, PUR
•Body: Polyamide
Top/Bottom (Cat. No. 450L-AM-TBM) mounting brackets:
• Bracket: Steel, powder coated
• Screws: Steel
Side mounting brackets (Cat. No. 450L-AM-SM):
•Body: Polyamide
• Screws: Steel
Replacement brackets (Cat. No. 450L-AM-RK):
• Bracket: Aluminum, black anodized
• Screws:Steel
Laser-alignment tool bracket (Cat. No. 450L-ALAT-C):
•Bracket: Polyamide
• Test rod: Aluminum
• Optical Interface Device (Cat. No. 450L-AD-OID): Polyamide
Stick dimensions • Cross section: 30 x 30 mm (1.19 x 1.19 in.)
• Length: N x 150 mm (N x 5.9 in.) [N = 1 … 13]
Screw type and maximum torque of top/
bottom mounting bracket
M3 x 10; Phillips screw
0.7 N•m (6.2 lb•in) max.
Screw type and maximum torque for M2
screws of plug-in
M2 x 8; Phillips screw
0.38 N•m (3.4 lb•in) max.
Maximum torque for screws of side
mounting bracket
• M6 screws: 11 N•m
• M4 screws: 2.8 N•m
Indicators stick 450L-B and 450L-E:
Transceiver type (Rx or Tx)
Status
Intensity (for two regions)
Start/Restart
Output
450L-E only:
Muting
Blanking
Cascading
Connection plug Depending on installed plug-in:
M12 5-pin (male) or M12 8-pin (male) fixed at pigtail with cable length:
Connection plug-ins: 150 mm (11.81 in.)
I/O cascading plug-in: 60 mm (2.36 in.);
Minimum outer bend radius of pigtail: > 3xD:
5-pin: D = 4.4 mm (0.17 in.)
8-pin: D = 5.5 mm (0.22 in.)
Connection cable length Maximum 100 m (330 ft) with wire section AWG 22 (Condition: Power supply 24V and
maximum load on outputs 50 mA total)
Accessories included Test rod, top/bottom mounting brackets and installation instruction
Silicon The unit does not release any silicone or other LABS-critical substances and is suitable
for use in paint shops.
