106 Rockwell Automation Publication 450L-UM001D-EN-P - December 2019
Chapter 6 Installation and Wiring
1732 ArmorBlock Connections
Figure 71 is an example of connecting to a 450L-B safety light curtain with 5-pin
transmitter and receiver plug-ins to a 1732ES-IB12XOB4 ArmorBlock module.
A 1485P-RDR5 splitter (see T-connector on page 104
) allows both the receiver
and transmitter to be connected to one input connector. The firmware for the
450L transceiver stick working as a transmitter must be 2.001 or larger. The
firmware level can be found on product label; see example of Product Labels on
page 126.
Figure 71 - Example Schematic for Connecting to a 450L-B Safety Light Curtain System
The DIP switch settings for the receiver plug-in module are shown in Ta ble 49.
Switches 2 and 3 can be set to ON, if needed by the application. The transmitter
plug-in does not have DIP switches.
Table 49 - DIP Switch Settings
Power
AE
BF
DH
CG
EtherNet
4
3
2
1
1
2
3
4
1 T1
2 I1
3 C
4 I0
5 T0
1 T1
2 I1
3 C
4 I0
5 T0
1 T1
2 I1
3 C
4 I0
5 T0
1 T1
2 I1
3 C
4 I0
5 T0
1 T1
2 I1
3 C
4 I0
5 T0
1 T1
2 I1
3 C
4 I0
5 T0
X100 X1X10
2 O1
1+24
3 C
4 O0
5 C
2 O1
1+24
3 C
4 O0
5 C
3
5
4
21
3
5
4
21
+24V DC
24V Com
K1
Brown (1) White (2)
Black (4)
Gray (5)
K2
100S or 700S or 700-HPS
Contactors and Relays
K2
1732ES-IB12XOB4
ReceiverTransmitter
450L-APT-PW-5
450L-B4FN1200YD
FW: 2.001
450L-B4FN1200YD
FW: All
450L-APR-ON-5
889D-F5NCDE-10
889D-F5NCDE-10
889D-E5NC-10
1485P-RDR5
5-pin Splitter
889D-E5NC-10
White (2) A1 A2 Blue (3)
Black (4) A1 A2 Gray (5)
K1
Switch 450L-APR-ON-5 Description Comment
1OFF—
2 OFF Low Range Disabled Optional
3 OFF Beam Coding Deactivated Optional
4OFF—
