Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 61
System Configuration Chapter 5
450L-APR-ON-5 Connection
Plug-in
Table 21 - Function and Default Settings
450L-APR-ED-8 Connection
Plug-in
Function and default settings for the M12 8-pin EDM receiver plug-in
(450L-APR-ED-8) inserted in a 450L transceiver stick 450L-APR-BL-5
connection plug-in are shown in Tabl e 22
.
Table 22 - Function and Default Settings
Switch Number Switch Function Default Description
1—OFF—
2 Low Range Activation OFF OFF: Disabled
ON: Enabled
3 450L-E only: Activates
Beam Coding
OFF OFF: Deactivated
ON: Activated
4—OFF—
Switch Number Switch Function Default Description
1—OFF—
2 Low Range Activation OFF OFF: Disabled
ON: Enabled
3 450L-E only: Activates
Beam Coding
OFF OFF: Disabled
ON: Enabled
4—OFF—
5 Combination activates the
following start modes:
• Automatic start
• Manual (re) start
• Manual cold start
• Manual start with off
function
OFF • DIP 5: OFF, DIP 6: OFF:
Automatic start
(Default)
• DIP 5: ON, DIP 6: OFF:
Manual (re) start
• DIP 5: OFF, DIP 6: ON:
Manual cold start
• DIP 5: ON, DIP 6: ON:
Manual start with off
function
6OFF
7External Device
Monitoring
OFF OFF: Disabled
ON: Enabled
8—OFF—
