Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 13
Product Overview Chapter 1
Figure 1 - Compatibility Limitations
Figure 2 - Assembly Overview for the 450L-B Safety Light Curtain System
Figure 3 - Assembly Overview for the 450L-E Safety Light Curtain System
A 450L-E safety light curtain also provides the option to insert a cascading plug-
in into the opposite stick end at the gray slot cover (see Cascading on page 48
and
Figure 5 on page 14
).
2 x 450L-B
1 x 450L-B
1 x 450L-E
2 x 450L-E
Standard
Mounting
Bracket
Transceive r
Sticks
Inserted Plug-ins
Connection
Plug-in
Inserted Connection
Plug-ins
Standard Mounting
Bracket
450L-E Transceiver
Sticks
Inserted Connection
Plug-ins
Cascading Plug-in
(Optional)
Connection Plug-in
