Figure 183 - 440L-AMSTD2M
60
(2.36)
12
(0.47)
2015
(79.3)
2000
(78.7)
60
(2.36)
24 (0.94)
30 (1.18)
3 x M12
R 5.50 (0.22)
10°
14
(0.55)
R 105 (4.13)
30
(1.18)
30 (1.18)
150
(5.91)
100
(3.94)
240 (9.45)
Base Plate
