66 Rockwell Automation Publication 450L-UM001D-EN-P - December 2019
Chapter 5 System Configuration
9. As soon as the status indicator changes from green/red blinking to green/
off blinking, release.
10. After releasing, the status indicator STS is solid green.
If any error occurs in this procedure, the new configuration is not stored and the
STS-indicator starts blinking again (1 Hz, green/red, and 50:50 duty cycle). For
example:
• If the actuator is released before the 5 seconds,
• It is not actuated within the 2 seconds thereafter.
IMPORTANT Once the configuration confirmation procedure is completed, verify that the
operating mode has changed to the intended configuration.
