Rockwell Automation Allen-Bradley GuardShield 450L-B4FNxYD

Rockwell Automation Publication 450L-UM001D-EN-P - December 2019 87
Installation and Wiring Chapter 6
Figure 58 - Replacement Mounting Kit (450L-AM-RK)
Figure 59 - Replacement Kit in Combination with the Default L-bracket
(450L-AM-TBM) and the Side-mounting Bracket (450L-AM-SM).
120 (4.72)
20 (0.79)
46
(1.81)
26.7 (1.05)
110 (4.33)
8.5
(0.33)
53.11
(2.09)
12.5
(0.49)
6
(0.23)
10
(0.39)
20 (0.79)
135 (5.31)
54
(2.11)
Adjustable
46.9
(1.85)
11
(0.43)
7
(0.30)
25
(0.98)
20
(0.79)
45
(1.77)
28.7
(1.13)
7
(0.30)
450L-AM-SM 450L-AM-SM
