5-6 Programming and Parameters
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
333 700L FaultStatus
Indicates the occurrence of exception events that have been configured as fault conditions for the PowerFlex 700L Liquid-Cooled drive.
Bit 0 [Dsat Phs U1] indicates that the primary structure detected a Dsat on phase U.
Bit 1 [Dsat Phs V1] indicates that the primary structure detected a Dsat on phase V.
Bit 2 [Dsat Phs W1] indicates that the primary structure detected a Dsat on phase W.
Bit 3 [Ovr Current1] indicates that the primary structure detected an over current.
Bit 4 [Ovr Volt1] indicates that the primary structure detected an over voltage.
Bit 5 [Asym DcLink1] indicates that the primary structure detected an unbalanced DC Link.
Bit 6 [Pwr Suply1] indicates that the primary structure detected a power supply failure.
Bit 7 [HW Disable1] indicates that the primary structure detected a hardware disable.
Bit 8 [Latch Err1] indicates that the primary structure fault was generated but no indicating bit was set.
Bit 9 [Fan Fail1] indicates
Bit 12 [NonCnfgAlarm] indicates
Bit 13 [Cnv Faulted] indicates
Bit 14 [Cnv NotLogin] indicates that the converter expected but none logged in.
Bit 15 [Cnv NotStart] indicates that the converter commanded to start but did not become active.
Bit 16 [Dsat Phs U2] indicates that the second structure detected a Dsat on phase U.
Bit 17 [Dsat Phs V2] indicates that the second structure detected a Dsat on phase V.
Bit 18 [Dsat Phs W2] indicates that the second structure detected a Dsat on phase W.
Bit 19 [Ovr Current2] indicates that the second structure detected an over current.
Bit 20 [Ovr Volt2] indicates that the second structure detected an over voltage.
Bit 21 [Asym DcLink2] indicates that the second structure detected an unbalanced DC Link.
Bit 22 [Pwr Suply2] indicates that the second structure detected a power supply failure.
Bit 23 [HW Disable2] indicates that the second structure detected a hardware disable.
Bit 24 [Latch Err2] indicates that the second structure fault was generated but no indicating bit was set.
Bit 25 [Fan Fail2] indicates
Note: This parameter was added for firmware version 2.03.
No.
Name
Description
Values
Bit
Definition
Reserved Reserved Reserved Reserved Reserved Reserved Fan Fail2 Latch Err2 HW Disable2 Pwr Suply2 Asym DcLink2 Ovr Volt2 Ovr Current2 Dsat Phs W2 Dsat Phs V2 Dsat Phs U2 Cnv NotStart Cnv NotLogin Cnv Faulted NonCnfgAlarm Reserved Reserved Fan Fail1 Latch Err1 HW Disable1 Pwr Suply1 Asym DcLink1 Ovr Volt1 Ovr Current1 Dsat Phs W1 Dsat Phs V1 Dsat Phs U1
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
