Programming and Parameters 5-7
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
334 700L AlarmStatus
Indicates the occurrence of exception events that have been configured as alarm conditions for the PowerFlex 700L Liquid-Cooled drive.
Bit 0 [NonCnfgFault] Not configured as alarm.
Bit 1 [NonCnfgFault] Not configured as alarm.
Bit 2 [NonCnfgFault] Not configured as alarm.
Bit 3 [NonCnfgFault] Not configured as alarm.
Bit 4 [NonCnfgFault] Not configured as alarm.
Bit 5 [NonCnfgFault] Not configured as alarm.
Bit 6 [NonCnfgFault] Not configured as alarm.
Bit 7 [NonCnfgFault] Not configured as alarm.
Bit 8 [NonCnfgFault] Not configured as alarm.
Bit 9 [NonCnfgFault] Not configured as alarm.
Bit 10 [NonCnfgFault] Not configured as alarm.
Bit 11 [NonCnfgFault] Not configured as alarm.
Bit 12 [Cnv Alarm]
Bit 13 [NonCnfgFault] Not configured as alarm.
Bit 14 [Cnv NotLogin]
Bit 15 [NonCnfgFault] Not configured as alarm.
Bit 16 [NonCnfgFault] Not configured as alarm.
Bit 17 [NonCnfgFault] Not configured as alarm.
Bit 18 [NonCnfgFault] Not configured as alarm.
Bit 19 [NonCnfgFault] Not configured as alarm.
Bit 20 [NonCnfgFault] Not configured as alarm.
Bit 21 [NonCnfgFault] Not configured as alarm.
Bit 22 [NonCnfgFault] Not configured as alarm.
Bit 23 [NonCnfgFault] Not configured as alarm.
Bit 24 [NonCnfgFault] Not configured as alarm.
Bit 25 [NonCnfgFault] Not configured as alarm.
Bit 26 [NonCnfgFault] Not configured as alarm.
Bit 27 [NonCnfgFault] Not configured as alarm.
Bit 28 [NonCnfgFault] Not configured as alarm.
Bit 29 [NonCnfgFault] Not configured as alarm.
Bit 30 [NonCnfgFault] Not configured as alarm.
Bit 31 [NonCnfgFault] Not configured as alarm.
Note: This parameter was added for firmware version 2.03.
420 Pwr Strct Mode
Displays the power structure used in the drive. This is an identifier to the firmware for power structure control.
Bit 0 = PowerFlex 700S Frame 1 to 6 (Lo Pwr Strct)
Bit 1 = PowerFlex 700S above Frame 6 (Hi Pwr Strct)
Bit 2 = PowerFlex 700L
Bit 3 = PowerFlex 700S Frame 12
Note: Bit 3 [Parallel Drv] was added for firmware version 3.01.
No.
Name
Description
Values
Bit
Definition
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
Cnv Alarm
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
NonCnfgFault
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
Bit
Definition
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Parallel Drv
PF 700L
Hi Pwr Strct
Lo PwrStrct
Default0000000000000000
Bit 1514131211109876543210
0 = False
1 = True
