A-8 Supplemental Drive Information
PowerFlex® 700L Liquid-Cooled Drive User Manual
Publication 20L-UM001D-EN-P
Table A.J 810 Volt DC Input Fusing
Table A.K 932 Volt DC Input Fusing
Drive
Catalog
Number
Frame
HP (kW) Rating
DC Input
Rating Bussmann Fuse
ND HD Amps Amps Catalog No.
20LE425 3A 465 (345) 345 (255) 850
(1)
(1)
Only the Dual Inverter for PowerFlex 700L Frame 3A is available as a DC input inverter.
1400 170M6701
(2)
(2)
Two 700A Bussmann 170M6695 fuses per phase can also be used.
20LE800 3B 870 (650) 640 (480) 800 1250 170M6700
(3)
(3)
Two 630A Bussmann 170M6694 fuses per phase can also be used.
20LE1K1 3B 1275 (955) 935 (695) 1175 900 (2 per phase) 170M6697
Drive
Catalog
Number
Frame
HP (kW) Rating
DC Input
Rating Bussmann Fuse
ND HD Amps Amps Catalog No.
20LF380 3A 475 (355) 350 (260) 760
(1)
(1)
Only the Dual Inverter for PowerFlex 700L Frame 3A is available as a DC input inverter.
1250 170M6700
(2)
(2)
Two 630A Bussmann 170M6694 fuses per phase can also be used.
20LF705 3B 881 (657) 650 (485) 705 1100 170M6699
(3)
(3)
Two 550A Bussmann 170M6693 fuses per phase can also be used.
20LF1K0 3B 1315 (980) 965 (720) 1050 800 (2 per phase) 170M6696
