Rosemount 5402 - Page 76

Reference Manual
00809-0100-4026, Rev FA
July 2009
Rosemount 5400 Series
5-22
Figure 5-11. HART Communicator Menu Tree corresponding to Device Revision 2.
Process Variables
1 Process Variables
2Setup
3 Diagnostics
4 Level
5 Analog Out
6 Distance
7 Signal Strength
1 Primary Variable
22nd
33rd
44th
5 All variables
6 Identification
1 Basic Setup
2 Device
3Tank
4 Analog output
5Echo Curve
6 Advanced
7Calibration
1 Diagnostics
2 Tools
1 Variable Mapping
2Geometry
3 Environment
4 Volume
5 Analog Out
6 Finish
1 Identification
2 Variable Mapping
3LCD
4 Communication
5 Alarm/Sat. Limits
1 Identification
2 Variable Mapping
3LCD
4 Communication
5 Alarm/Sat. Limits
1Geometry
2 Environment
3 Volume
4 Antenna
1 Analog Out
2 Alarm/Sat. Limits
1 Echo Peaks
2 Echo Curve
1Empty Tank
2 Echo Tracking
3 Double Bounce
4 Bottom Projection
5 Double Surface
6 Filter Settings
7 Full Tank
1 Analog Output
Setup
Diagnostics
1 Primary Variable
2 2nd
33rd
44th
5 HART Digital Units
6 Damping Value
7 Device Status
1 Tank Type
2 Tank Bottom Type
3 Tank Height
4 Still-pipe/Bridle Meas
5 Drawing
1 Process Condition
2 Product Dielectric
Range
1 Volume Calculation
Method
2 Drawing
1 Primary Variable
2 Range Values
3 Alarm Mode
4 Sensor Limit
5 Alarm Mode
Definition
2 Measure and Learn
4Restart Device
1 Found Echo Peaks
2 Measurement Output
3 Register False
Echoes
4 Add False Echo
5 Remove False Echo
1 Measure and Learn
2 Set Threshold
3 Echo Curve
