Reference Manual
00809-0100-4026, Rev FA
July 2009
5-23
Rosemount 5400 Series
Table 5-4. HART Fast Key Sequences
Function HART Fast Key
Alarm Mode 2, 1, 5, 3
Antenna Type 2, 3, 4
Device Information 2, 2, 1
LCD Language 2, 2, 3
LCD Variables 2, 2, 3
Length Unit 2, 1, 1, 5
Lower Range Value (LRV) (4 mA) 2, 1, 5, 2
Pipe Diameter 2, 1, 2, 4
Primary Variable 2, 1, 1, 1
Product Dielectric Constant 2, 1, 3, 2
Range Values (LRV/URV) 2, 1, 5, 2
Tag 2, 2, 1
Tank Bottom Type 2, 1, 2, 2
Tank Height 2, 1, 2, 3
Tank Type 2, 1, 2, 1
Temperature Unit 2, 1, 1, 5
Hold Off Distance/Upper Null Zone 2, 3, 4
Upper Range Value (URV) (20 mA) 2, 1, 5, 2
Volume Configuration 2, 1, 4, 1
Volume Unit 2, 1, 1, 5
