IIT-2000/2010/5000/5010 Instruction Manual/English
88 05/08/2015 Version No. 001
2. The settings of a previous test can be loaded by
pressing the corresponding soft-key in the VIEW or
READY status.
For example, if you are currently in DCW mode,
pressing the ACW key will load the ACW settings
that were previously used in the special manual
mode.
A CW
Example:
ACW
3. Set all the necessary parameters for a test and
save.
Note: A different test setup can be saved for each
test function (ACW, DCW, IR and GB).
Pages
45~71
I R G B A CW D C W
E
F R E Q = 0 H z 6
0 100
k V
EIV
S T A . t = 0 0 0 0 . 1 S MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
W
MM A UN N A_0M A N U = * * * - 0 0
m A
ESW E S T A . tP
IIT-5010/2010 shown.
Note
The TIMER settings can be set OFF when in the special test
mode for ACW and DCW tests.
If the TIMER settings are set to OFF, the sweep function will
not produce a graph.
