1-31
μm)
button (up/down)
TRIM thickness setting button
Various Settings
Setting the TRIM Thickness
You can set the section thickness for specimen trimming (rough shaving) on the [UTILITIES] Tab Screen.
The value set here applies to both manual sectioning and motorized sectioning.
1. Press the "TRIM Thickness Setting" button on the
[UTILITIES] Tab Screen.
2. The TRIM thickness change screen appears.
3. Press the ""/"" buttons among the "Value Change"
buttons to change the value of section thickness.
The settable range is 5 to 99 µm. A desired value can be set
as a multiple of 5 µm.
4. Pressing the “Enter” button saves the setting, after which the
display returns to the [UTILITIES] Tab Screen.
If no operation has been performed for 5 minutes, the setting is
not saved and the screen closes automatically.
