Sakura Tissue-Tek Polar DM User Manual

2-9
Preparing for Sectioning
Adjusting the Lateral Movement of the Blade Holder
You can slide the blade holder to the left and right.
This way, the set disposable blade can be used fully.
1. Tilt toward you the blade holder left/right lever indicated in yellow
and found on the left of the blade holder, to unlock the blade
holder.
2. Adjust the blade holder that now moves to the left and right.
3. When the adjustment is complete, tilt away from you the blade
holder left/right lever shown in yellow, to lock the blade holder.
If the blade holder stops moving to the left and right, tilt all the
way toward you the blade holder left/right lever with a yellow
ring, to remove and clean the lever.
Refer to p. 3-7 for the cleaning method.
The black handle of each lever on the blade holder can be set at
any angle.
After the lever is set to the lock position, pull the handle
outward [1] and turn it to a desired position [2]. Release the
handle to lock it.
Lever (yellow) (Blade holder left/right lever)
Left position
Normal position
Right position
Black lever handle
