Date Code 990430 Overcurrent, Voltage, Synchronism Check, and Frequency Elements 3-17
SEL-351P Manual Técnico
Table SECTION 3: .2: Phase Time-Overcurrent Elements Settings
Setting Definition Range
51P1P
51P2P
pickup
0.10 - 3.20 A secondary (1 A nominal phase
current inputs, IA, IB, IC)
51P1C
51P2C
curve type U1 - U5 (US curves), C1 - C5 (IEC curves),
recloser or user curves
see Figure 9.1 - Figure 9.20
51P1TD
51P2TD
time dial (has no multiplying
effect on constant time adder
or minimum response time)
0.50 - 15.00 (US curves), 0.05 - 1.00 (IEC
curves), 0.10 - 2.00 (recloser or user curves)
see Figure 9.1 - Figure 9.20
51P1RS
51P2RS
electromechanical reset
timing
Y, N
51P1CT
51P2CT
constant time adder – adds
additional time to curve
0.00 - 60.00 cycles
(no effect if set = 0.00)
51P1MR
51P2MR
minimum response time –
flattens curve at set time;
curve can operate no faster
than this set time
0.00 - 60.00 cycles
(no effect if set = 0.00)
51P1TC
51P2TC
SEL
OGIC
Control Equation
torque control setting
Relay Word bits referenced in Table 9.3
or
set directly to logical 1 (=1) – see note below
Note: SEL
OGIC
Control Equation torque control settings (e.g., 51P1TC) cannot be set directly
to logical 0.
See Section 9: Setting the SEL-351P Recloser Control for additional time-overcurrent element
setting information.
