Date Code 991201 Distributed Network Protocol (DNP) V3.00 H-3
SEL-351P Manual Técnico
Data Retrieval Method Description Relevant SEL-351P Settings
Quiescent The master never polls and relies
on unsolicited reports only.
Set ECLASS to a non-zero value,
Set UNSOL = Y,
Set NUMEVE and AGEEVE
according to how often messages are
desired to be sent.
D
EVICE
P
ROFILE
The following is the device profile as specified in the
DNP V3.00 Subset Definitions
document:
DNP V3.00
DEVICE PROFILE DOCUMENT
This document must be accompanied by a table having the following headings:
Object Group Request Function Codes Response Function Codes
Object Variation Request Qualifiers Response Qualifiers
Object Name (optional)
Vendor Name: Schweitzer Engineering Laboratories, Inc.
Device Name: SEL-351P
Highest DNP Level Supported:
For Requests Level 2
For Responses Level 2
Device Function:
Master Slave
Notable objects, functions, and/or qualifiers supported in addition to the Highest DNP Levels Supported
(the complete list is described in the attached table):
Supports enabling and disabling of unsolicited reports on a class basis.
Maximum Data Link Frame Size (octets):
Transmitted 292
Received (must be 292)
Maximum Application Fragment Size (octets):
Transmitted 2048
(if >2048, must
be configurable)
Received 2048
(must be >249)
Maximum Data Link Re-tries:
None
Fixed at
Configurable, range 0
to 15
Maximum Application Layer Re-tries:
None
Configurable, range
to
(Fixed is not permitted)
