10-38 Serial Port Communications and Commands Date Code 990215
SEL-351P Manual Técnico
TAR 43
PB9 32NF 32NR * WBTRT SF6LO DISCHG LED9
TAR 44
LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8
TAR 45
OCP OCG OLP OLG OLS HTP HTG HLP
TAR 46
HLG CLP RPP RPG RPS SEQC 3PHV GTP
TAR 47
1
RMB8A RMB7A RMB6A RMB5A RMB4A RMB3A RMB2A RMB1A
TAR 48
1
TMB8A TMB7A TMB6A TMB5A TMB4A TMB3A TMB2A TMB1A
TAR 49
1
RMB8B RMB7B RMB6B RMB5B RMB4B RMB3B RMB2B RMB1B
TAR 50
1
TMB8B TMB7B TMB6B TMB5B TMB4B TMB3B TMB2B TMB1B
TAR 51
1
LBOKB CBADB RBADB ROKB LBOKA CBADA RBADA ROKA
TAR 52
* * * * * * * *
TAR 53
* * * * * * * *
TAR 54
* * * * * * * *
TAR 55
* * * * * * * *
TAR 56
RAW52B RAW52A WB52A WBBRK WBCL WBTR CLCAP TRCAP
TAR 57
* * * * * * * *
TAR 58
* * * * * * * *
TAR 59
* * * * * * * *
1. M IRRORED B ITS elements only valid in firmware versions 1 or greater.
Command TAR SH1 10 is executed in the following example:
=>TAR SH1 10 <ENTER>
79RS 79CY 79LO SH0 SH1 SH2 SH3 SH4
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
79RS 79CY 79LO SH0 SH1 SH2 SH3 SH4
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
=>
Note that Relay Word row containing the SH1 bit is repeated 10 times. In this example, the
reclosing function is in the Lockout State (79LO = logical 1) and the shot is at shot = 2 (SH2 =
logical 1). Command TAR 32 will report the same data since the SH1 bit is in Row 32 of the
Relay Word.
TIM Command (View/Change Time)
TIM displays the recloser control clock. To set the clock, type TIM and the desired setting, then
press <ENTER>. Separate the hours, minutes, and seconds with colons, semicolons, spaces,
commas, or slashes. For example, to set the clock to 23:30:00, enter:
