Schweitzer Engineering SEL-351P - Front-Panel Interface; Figure 7: SEL-351 P Recloser Control Front-Panel Interface

Front-Panel Interface
SEL-351P Quick-Start Installation and User's Guide (Portuguese) 25
FRONT-PANEL INTERFACE
Topics covered in this section:
• Status and Trip Target LEDs
• Pushbuttons
• Operator Controls
DWG: MP351P058
Display (default
display shows IA,
IB, IC, and IN
primary currents)
Pushbuttons
Status and Trip
Target LEDs
Operator
Controls
Figure 7: SEL-351P Recloser Control Front-Panel Interface
