The output from an SEL-351P with three-phase wye-connected voltage inputs is shown:
=>MET D <ENTER>
RECLOSER R1 Date: 02/01/97 Time: 15:08:05.615
FEEDER 2101
IA IB IC IN IG 3I2
DEMAND 188.6 186.6 191.8 0.2 4.5 4.7
PEAK 188.6 186.6 191.8 0.3 4.5 4.7
MWA MWB MWC MW3P MVARA MVARB MVARC MVAR3P
DEMAND IN 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
PEAK IN 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
DEMAND OUT 2.2 2.2 2.2 6.6 0.3 0.3 0.3 0.9
PEAK OUT 3.1 3.1 3.1 9.3 0.4 0.4 0.4 1.2
LAST DEMAND RESET 01/27/97 15:31:51.238 LAST PEAK RESET 01/27/97 15:31:56.239
=>
=>
Reset the accumulated demand values using the MET RD command. Reset the peak demand
values using the MET RP command. For more information on demand metering, see Demand
Metering in Section 8: Breaker/Recloser Monitor, Battery System Monitor, Metering, and
Load Profile Functions.
MET E – Energy Metering
The MET E command displays the following quantities:
Energy MWh
A,B,C
Single-phase megawatt hours (in and out; wye-connected voltage
inputs only)
MWh
3P
Three-phase megawatt hours (in and out)
MVARh
A,B,C
Single-phase megavar hours (in and out; wye-connected voltage
inputs only)
MVARh
3P
Three-phase megavar hours (in and out)
Reset Time Last time the energy meter was reset
To view energy metering values, enter the command:
=>MET E <ENTER>
The output from an SEL-351P with three-phase wye-connected voltage inputs is shown:
=>MET E <ENTER>
RECLOSER R1 Date: 02/01/97 Time: 15:11:24.056
FEEDER 2101
MWhA MWhB MWhC MWh3P MVARhA MVARhB MVARhC MVARh3P
IN 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
OUT 36.0 36.6 36.7 109.2 5.1 5.2 5.3 15.6
LAST RESET 01/31/97 23:31:28.864
=>
