Date Code 990215 Serial Port Communications and Commands 10-5
SEL-351P Manual Técnico
SEL-351P Recloser Control to SEL-PRTU
Cable C231
SEL-PRTU
SEL-351P
9-Pin Male 9-Pin Male
Round Conxall “D” Subconnector
GND 1 5 GND
TXD 2 2 RXD
RXD 4 3 TXD
CTS 5 7 RTS
+12 7 8 CTS
GND 9 9 GND
SEL-351P Recloser Control to SEL-2020
Cable C273A
SEL-2020
SEL-351P
9-Pin Male 9-Pin Male
“D” Subconnector “D” Subconnector
RXD 2 3 TXD
TXD 3 2 RXD
IRIG+ 4 4 IRIG+
GND 5 5 GND
IRIG- 6 6 IRIG-
RTS 7 8 CTS
CTS 8 7 RTS
* DTE = Data Terminal Equipment (Computer, Terminal, Printer, etc.)
** DCD = Data Communications Equipment (Modem, etc.)
