Communications
SEL-351P Quick-Start Installation and User's Guide (Portuguese) 17
Table 2: SEL-351P Recloser Control Command Summary
Access Level
and
Available
Commands
Description
Corresponding
Front-Panel
Pushbutton
Access
Level 0
The only operation that can be performed at Access Level 0 is to go to
Access Levels 1 or E. The screen prompt is: = (see
Table 4
)
ACC Enter Access Level 1.
EZA Enter Access Level E.
Access
Level 1
The Access Level 1 commands primarily allow the user to look at
information (e.g., settings, metering), not change it. The screen prompt
is: => (see
Table 4
)
2AC Enter Access Level 2.
BAC Enter Breaker Access Level (Access Level B).
BRE A Display breaker monitor data (trips, interrupted current, wear). OUTROS
DAT Show date. OUTROS
DAT m/d/y Enter date in this manner if Date Format setting DATE_F = MDY. OUTROS
DAT y/m/d Enter date in this manner if Date Format setting DATE_F = YMD. OUTROS
EVE n Show event report number n with 1/4-cycle resolution.
EVE L n Show event report number n with 1/16-cycle resolution.
EVE R n Show raw event report number n with 1/16-cycle resolution.
EVE C n Show compressed event report number n for use with SEL-5601 Analytic
Assistant.
EZA Enter EZ Access Level (Access Level E).
GRO Display active group number. GRUPO
HIS n Show brief summary of the n latest event reports. EVENTOS
HIS C Clear the brief summary and corresponding event reports.
IRI Force synchronization attempt of internal relay clock to IRIG-B time-code
input.
MET k Display instantaneous metering data. Enter k for repeat count. MEDIÇÃO
MET D Display demand and peak demand data. MEDIÇÃO
MET E Display energy metering data. MEDIÇÃO
MET M Display maximum/minimum metering data. MEDIÇÃO
MET RD Reset demand metering data. MEDIÇÃO
MET RE Reset energy metering data. MEDIÇÃO
MET RM Reset maximum/minimum metering data. MEDIÇÃO
MET RP Reset peak demand metering data. MEDIÇÃO
