Date Code 990430 Factory-Set Logic 1-5
SEL-351P Manual Técnico
EZ Global Settings
(SHO FZ command; SET FZ command)
Corresponding “Regular” Global Settings
(SHO G command; SET G command)
System Frequency
Phase Rotation
NFREQ
PHROT
Recloser Wear Monitor (AUTO, Y, N)
Interrupt rating
EBMON
COS1, COS2, COS3
KASP1, KASP2, KASP3
Reset trip-latched LEDs when recloser closes
(Y/N)
RSTLED
True three-phase voltage connected (Y/N) 3PVOLT
Battery Amp-hours
% Battery capacity for sleep
AMPHR
SLPCAP
Turn on the 12 V power (Y/N)
Keep the 12 V power on while asleep (Y/N)
ON12V
12VSLP
SF6 low pressure warning threshold SF6PRS
Overcurrent Element Functions Overview
When the factory default EZ settings are active for a particular settings group, many of the
overcurrent elements in that settings group have specific functions, as explained in Table 1.2.
Table SECTION 1: .2: Overcurrent Element Functions with EZ Settings Operative
Overcurrent Element Function with EZ Settings
Operative
Associated Settings
51P1T Fast curve - phase 51P1P, 51P1C, 51P1TD,
51P1RS, 51P1CT, 51P1MR
51G1T, 51N1T Fast curve - ground 51G1P, 51G1C, 51G1TD,
51G1RS, 51G1CT, 51G1MR
51N1P, 51N1C, 51N1TD,
51N1RS, 51N1CT, 51N1MR
51P2T Delay curve - phase 51P2P, 51P2C, 51P2TD,
51P2RS, 51P2CT, 51P2MR
51G2T, 51N2T Delay curve - ground 51G2P, 51G2C, 51G2TD,
51G2RS, 51G2CT, 51G2MR
51N2P, 51N2C, 51N2TD,
51N2RS, 51N2CT, 51N2MR
67N3T SEF element 50N3P, 67N3D
67P2T High current trip - phase 50P2P, 67P2D
67G2T, 67N2T High current trip - ground 50G2P, 67G2D,
