1-4 Factory-Set Logic Date Code 990430
SEL-351P Manual Técnico
EZ Recloser Control Settings
(SHO EZ n command; SET EZ n command)
Corresponding “Regular” Settings
(SHO n command; SET n command)
High current trip - ground (Y/N)
High current trip - ground
Time delay - ground high current trip
Activate high current trip - ground
50G2P
50N2P
67G2D
67N2D
HITRGR
High current lockout - phase (Y/N)
High current lockout - phase
Activate high current lockout - phase
50P1P
HILKPH
High current lockout - ground (Y/N)
High current lockout - ground
Activate high current lockout - ground
50G1P
50N1P
HILKGR
Cold load pickup scheme (Y/N)
Cold load pickup - phase
Cold load pickup - ground
Loss of load diversity time
50P5P, ECOLDP
50G5P, ECOLDG, 50N5P
SV6PU
Restore min. trips - time limit
Restore min. trip - phase
Restore min. trip - ground
Restore min. trip - SEF
SV5PU
RPPH
RPGR
RPSEF
Sequence coordination (Y/N)
Ground trip precedence (Y/N)
ESEQ
PRECED
Underfrequency loadshedding (Y/N)
Underfrequency pickup
Underfrequency time delay
81D1P
81D1D
Demand meter time constant DMTC
