Date Code 990430 Factory-Set Logic 1-3
SEL-351P Manual Técnico
EZ Recloser Control Settings
(SHO EZ n command; SET EZ n command)
Corresponding “Regular” Settings
(SHO n command; SET n command)
Operations to lockout - SEF OPLKSF
Reclose interval 1
Reclose interval 2
Reclose interval 3
Reclose interval 4
790I1
790I2
790I3
790I4
Reset time for auto reclose
Reset time from lockout
Close power wait time
79RSD
79RSLD
79CLSD
Complex fast curve - phase (Y/N)
Const. time adder - phase fast curve
Vert. multiplier - phase fast curve
Min. response - phase fast curve
51P1CT
51P1TD
51P1MR
Complex fast curve - ground (Y/N)
Const. time adder - ground fast curve
Vert. multiplier - ground fast curve
Min. response - ground fast curve
51G1CT
51N1CT
51G1TD
51N1TD
51G1MR
51N1MR
Complex delay curve - phase (Y/N)
Const. time adder - phase delay curve
Vert. multiplier - phase delay curve
Min. response - phase delay curve
51P2CT
51P2TD
51P2MR
Complex delay curve - ground (Y/N)
Const. time adder - ground delay curve
Vert. multiplier - ground delay curve
Min. response - ground delay curve
51G2CT
51N2CT
51G2TD
51N2TD
51G2MR
51N2MR
High current trip - phase (Y/N)
High current trip - phase
Time delay - phase high current trip
Activate high current trip - phase
50P2P
67P2D
HITRPH
