SPECIFICATIONS
Battery Charger
Ac Voltage Input
Input Power: 106 - 140 Vac, 120 Vac nominal.
12 Vdc Output
11 - 14 Vdc, 6 W continuous, 13 W for 1 second.
Ac Voltage Inputs
Voltage Inputs V
A
, V
B
, V
C
, and V
S
.
300 V
L-N
continuous (connect any voltage up to 300 Vac). 600 V
L-N
for 10
seconds.
Burden: 0.03 VA @ 67 V; 0.06 VA @ 120 V; 0.8 VA @ 300 V.
Ac Current
Inputs
1 A nominal: 3 A continuous, 100 A for 1 second, linear to 20 A symmetrical.
250 A for 1 cycle.
Burden: 0.13 VA @ 1 A, 1.31 VA @ 3 A.
Sensitive Earth Fault:
0.05 A nominal channel IN current input: 1.5 A continuous, 20 A for 1 second,
linear to 1.5 A symmetrical.
100 A for 1 cycle.
Burden: 0.0004 VA @ 0.05 A, 0.36 VA @ 1.5 A.
Frequency and
Rotation
60/50 Hz system frequency and ABC/ACB phase rotation are user-settable.
Frequency tracking range: 40.1 - 65 Hz (V
A
required for frequency tracking).
Output Contacts
Except Trip and
Close
Per IEC 255-0-20 : 1974, using the simplified method of assessment:
6 A continuous carry
30 A make per IEEE C37.90 : 1989
100 A for one second
270 Vac/360 Vdc MOV for differential surge protection
Pickup/dropout time: < 5 ms
Breaking Capacity (L/R = 40 ms):
24 V 0.5 A 10,000 operations
48 V 0.5 A 10,000 operations
125 V 0.3 A 10,000 operations
250 V 0.2 A 10,000 operations
Cyclic Capacity (L/R = 40 ms):
24 V 0.5 A 2.5 cycles per second
48 V 0.5 A 2.5 cycles per second
125 V 0.3 A 2.5 cycles per second
250 V 0.2 A 2.5 cycles per second
Trip and Close
Outputs
Trip and close GVR recloser 10000 times without appreciable wear.
Optoisolated
Input Ratings
250 Vdc: on for 200 - 300 Vdc; off below 150 Vdc
125 Vdc: on for 105 - 150 Vdc; off below 75 Vdc
48 Vdc: on for 38.4 - 60 Vdc; off below 28.8 Vdc
24 Vdc: on for 16.0 - 30 Vdc.
With nominal control voltage applied, each optoisolated input draws approximately
4 mA of current.
