Date Code 991201 Distributed Network Protocol (DNP) V3.00 H-9
SEL-351P Manual Técnico
D
ATA
M
AP
The following is the default object map supported by the SEL-351P (FID = SEL-351P-Rxxx-V0-
Dxxxxxx).
Table APPENDIX H: .3: SEL-351P DNP Data Map
DNP Object Type Index Description
01,02 000 - 499 Relay Word, where 50B3 is 0 and 67P2S is 319.
01,02 500 - 999 Relay Word from the SER, encoded same as inputs
000 - 499 with 500 added.
01,02 1000 - 1015 Relay front-panel targets, where 1015 is RESET, 1008
is SEF, 1007 is CONTROL ENABLED, and 1000 is 81.
01,02 1016 - 1019 Power factor leading for A-, B-, C-, and 3-phase.
01,02 1020 Relay Disabled.
01,02 1021 Relay diagnostic failure.
01,02 1022 Relay diagnostic warning.
01,02 1023 New relay event available.
01,02 1024 Settings change or relay restart.
10,12 00 - 07 Remote bits RB1 - RB8.
10,12 08 Pulse Open command OC.
10,12 09 Pulse Close command CC.
10,12 10 Reset demands.
10,12 11 Reset demand peaks.
10,12 12 Reset energies.
10,12 13 Reset breaker monitor.
10,12 14 Reset front-panel targets.
10,12 15 Read next relay event.
10,12 16 - 19 Remote bit pairs RB1 - RB8.
10,12 20 Open/Close pair OC & CC.
20,22 00 Active settings group.
20,22 01 Internal breaker trips.
20,22 02 External breaker trips.
30,32 00,01 IA magnitude and angle.
30,32 02,03 IB magnitude and angle.
30,32 04,05 IC magnitude and angle.
