H-10 Distributed Network Protocol (DNP) V3.00 Date Code 991201
SEL-351P Manual Técnico
DNP Object Type Index Description
30,32 06,07 IN magnitude and angle.
30,32 08,09 VA magnitude (kV) and angle.
30,32 10,11 VB magnitude (kV) and angle.
30,32 12,13 VC magnitude (kV) and angle.
30,32 14,15 VS magnitude (kV) and angle.
30,32 16,17 IG magnitude and angle.
30,32 18,19 I1 magnitude and angle.
30,32 20,21 3I2 magnitude and angle.
30,32 22,23 3V0 magnitude (kV) and angle.
30,32 24,25 V1 magnitude (kV) and angle.
30,32 26,27 V2 magnitude (kV) and angle.
30,32 28 - 31 MW A-, B-, C-, and 3-phase.
30,32 32 - 35 MVAR A-, B-, C-, and 3-phase.
30,32 36 - 39 Power factor A-, B-, C-, and 3-phase.
30,32 40 Frequency.
30,32 41 Always read as 0.
30,32 42,43 A-phase MWhr in and out.
30,32 44,45 B-phase MWhr in and out.
30,32 46,47 C-phase MWhr in and out.
30,32 48,49 3-phase MWhr in and out.
30,32 50,51 A-phase MVARhr in and out.
30,32 52,53 B-phase MVARhr in and out.
30,32 54,55 C-phase MVARhr in and out.
30,32 56,57 3-phase MVARhr in and out.
30,32 58 - 63 Demand IA, IB, IC, IN, IG, and 3I2 magnitudes.
30,32 64 - 67 A-, B-, C-, and 3-phase demand MW in.
30,32 68 - 71 A-, B-, C-, and 3-phase demand MVAR in.
30,32 72 - 75 A-, B- C-, and 3-phase demand MW out.
30,32 76 - 79 A-, B-, C-, and 3-phase demand MVAR out.
30,32 80 - 85 Peak demand IA, IB, IC, IN, IG, and 3I2 magnitudes.
30,32 86 - 89 A-, B-, C-, and 3-phase peak demand MW in.
30,32 90 - 93 A-, B-, C-, and 3-phase peak demand MVAR in.
30,32 94 - 97 A-, B-, C-, and 3-phase peak demand MW out.
30,32 98 - 101 A-, B-, C-, and 3-phase peak demand MVAR out.
30,32 102 - 104 Breaker contact wear percentage (A, B, C).
