3-26 Overcurrent, Voltage, Synchronism Check, and Frequency Elements Date Code 990430
SEL-351P Manual Técnico
Settings Ranges
Table SECTION 3: .5: Residual Ground Time-Overcurrent Elements Settings
Setting Definition Range
51G1P
51G2P
pickup 0.10 - 3.20 A secondary (1 A nominal phase
current inputs, IA, IB, IC)
51G1C
51G2C
curve type U1 - U5 (US curves), C1 - C5 (IEC curves),
recloser or user curves
see Figure 9.1 - Figure 9.20
51G1RS
51G2RS
electromechanical reset
timing
Y, N
51G1TD
51G2TD
time dial (has no multiplying
effect on constant time adder
or minimum response time)
0.50 - 15.00 (US curves), 0.05 - 1.00 (IEC
curves), 0.10 - 2.00 (recloser or user curves)
see Figure 9.1 - Figure 9.20
51G1CT
51G2CT
constant time adder – adds
additional time to curve
0.00 - 60.00 cycles
(no effect if set = 0.00)
51G1MR
51G2MR
minimum response time –
flattens curve at set time;
curve can operate no faster
than this set time
0.00 - 60.00 cycles
(no effect if set = 0.00)
51G1TC
51G2TC
SEL OGIC Control Equation
torque control setting
Relay Word bits referenced in Table 9.3
or
set directly to logical 1 (= 1) or logical 0 (= 0)
– see note below
Note: If SEL OGIC Control Equation torque control setting 51G1TC is set directly to logical 0
(i.e., 51G1TC = 0), then corresponding residual ground time-overcurrent element 51G1T
is defeated
and nonoperational, regardless of any other setting. 51G2T is similar.
See Section 9: Setting the SEL-351P Recloser Control for additional time-overcurrent element
setting information.
Accuracy
Pickup: ±0.01 A secondary and ±3% of setting (1 A nominal phase current inputs, IA, IB, IC)
Curve Timing: ±1.50 cycles and ±4% of curve time for currents between (and including) 2
and 30 multiples of pickup
