Settings
60 SEL-351P Quick-Start Installation and User's Guide (Portuguese)
Global EZ Settings
No. Setting Default Range Incr.
38 System Frequency 60 50, 60 Hz
Enter nominal System frequency.
No. Setting Default Range Incr.
39 Phase Rotation ABC ABC, ACB
Enter system Phase rotation.
No. Setting Default Range Incr.
40 Recloser Wear Monitor AUTO AUTO, Y, N
Recloser Wear Monitor = Y:
The recloser wear monitor must be set at a higher level, with the SET G command (see the SEL-351P
Manual Técnico). This setting is usually selected if a circuit breaker is connected to the SEL-351P
instead of a GVR recloser.
Recloser Wear Monitor = N:
The recloser wear monitor is turned off.
Recloser Wear Monitor = AUTO:
This setting is usually selected if a GVR recloser is connected to the SEL-351P. Enter the following
setting:
Setting Default Range Incr.
Interrupt rating 6000 6000, 8000, 12000 Amps primary 1
These settings are derived from Whipp & Bourne Switchgear: Installation, Operation, and
Maintenance Manual, GVR Auto-Recloser, Issue C, July 1996, section 5.2.2 Vacuum Interrupters.
Make these settings by finding your recloser model in
Table 10 and then entering the corresponding
settings.
• This setting is hidden and nonoperative if Recloser Wear Monitor ≠ AUTO.
Table 10: Recloser Interrupt Data
Recloser Model Interrupt Rating (Amps primary)
GVR (15 kV, 6kA) 6000
GVR (15 kV, 12 kA) 12000
GVR (27 kV, 12 kA) 12000
GVR (38 kV, 8 kA) 8000
