Schweitzer Engineering SEL-351P - Pushbutton Primary Functions

Front-Panel Interface
28 SEL-351P Quick-Start Installation and User's Guide (Portuguese)
Pushbutton Primary Functions
Primary
Function
Corresponding
Serial Port
Command
Access Level
Password for
Front-Panel
Access
Description
TARGET
RESET
LED
TESTE
TAR R
1 None Illuminate all front-panel LEDs for 1
second and clear trip-latched targets TRIP,
CURVA RÁPIDA, ALTA CORRENTE,
RELÉ FREQ., A, B, C, N, and SEF.
MEDIÇÃO
Primary
Functions
Corresponding
Serial Port
Command Access Level
Password for
Front-Panel
Access Description
INST MET
1 None Display instantaneous magnitudes (and
angles if applicable) of meter values.
ENERGY
DISPLAY
RESET
MET E
MET RE
1
1
None
None
Display energy meter values.
Reset energy meter values.
MAX/MIN
DISPLAY
RESET
MET M
MET RM
1
1
None
None
Display maximum/minimum metering
values.
Reset maximum/minimum metering values.
DEMAND
DISPLAY
RESET
MET D
MET RD
MET RP
1
1
1
None
None
None
Display demand and peak demand meter
values.
Reset demand meter values.
Reset peak meter values.
Primary
Function
Corresponding
Serial Port
Command
Access Level
Password for
Front-Panel
Access
Description
EVENTOS
HIS 1 None Show SEL-351P event data.
