SETTINGS
This section details the EZ (“easy”) settings – the settings used to
perform traditional recloser control operations.
Topics covered in this section:
• Curve Designations
• EZ (“Easy”) Settings
• Global EZ Settings
• EZ Settings Sheets (end of Settings section)
Curve Information
Fast and delay curves are available for phase and ground overcurrent
protection. These curves can be set with any of the numerous resident
curve choices:
• Recloser Curves (see
Table 6)
• US Curves (see
Table 7)
• IEC Curves (see
Table 7)
• User-Programmable Curves (see
Table 7)
The recloser curves in
Table 6 show both the older electronic control
designation and the newer microprocessor-based control designation.
The recloser curves can be specified in a curve setting using either
designation. For example, a given traditional recloser curve has the
following two designations:
Older electronic control designation: A
Newer microprocessor-based control designation: 101
Traditional recloser curve A and curve 101 are the same curve
– use
either designation in making curve settings in the SEL-351P.
Important:
This Quick-Start Installation
and User's Guide provides only
information applicable to the EZ
settings - settings associated
with traditional recloser control
operations.
High Current Options
Available for Phase and
Ground:
• High Current Trip
• High Current Lockout
Curve Modifiers Available
for Any Curve Type:
• Constant Time Adder
• Vert. Multiplier/Time Dial
• Min. Response Time
