Front-Panel Interface
SEL-351P Quick-Start Installation and User's Guide (Portuguese) 33
Press the ABRIR operator control pushbutton to trip the recloser
(and take the control to the lockout state). Corresponding
RELIGADOR ABERTO LED illuminates to indicate the recloser is
open.
Option
: Set a delay, so the operator can press the ABRIR operator
control pushbutton and then move a safe distance away from the
recloser before the SEL-351P issues a trip (the ABRIR operator
control comes with no set delay in the factory settings). With a set
delay, press the ABRIR operator control pushbutton momentarily
and notice the corresponding RELIGADOR ABERTO LED flashes
on and off during the delay time, indicating a pending trip. Abort
the pending trip by pressing the ABRIR operator control pushbutton
again or by pressing the FECHAR operator control pushbutton.
This delay setting for the ABRIR operator control is PB9D (range: 0
to 3600 cycles; factory-set at 0 cycles – no delay). The delay is set
via the SET G command (PB9D is not an EZ Setting). See
Section 1: Factory-Set Logic in the SEL-351P Manual Técnico
for more information.
ABRIR
RELIGADOR
ABERTO
