SEL-351P Quick-Start Installation and User's Guide (Portuguese) 37
Table 8: EZ Settings Quick Reference
No. Settings Groups 1 (Main) and 2 (Alternate) EZ
Settings:
Factory Settings:
1
Control Identifier RECLOSER R1
2
Circuit Identifier FEEDER 2101
3
CT Ratio 200.0
4
PT Ratio 100.0
5
Min. trip - phase (A pri.) 200.00
6
Min. trip - ground (A pri.) 50.00
7
Min. trip - SEF (A pri.) OFF
8
Fast curve - phase A
Time dial - phase fast curve 1.00*
EM reset - phase fast curve N*
9
Fast curve - ground 1
Time dial - ground fast curve 1.00*
EM reset - ground fast curve N*
10
Delay curve - phase C
Time dial - phase delay curve 1.00*
EM reset - phase delay curve N*
11
Delay curve - ground 13
Time dial - ground delay curve 1.00*
EM reset - ground delay curve N*
12
Time delay - SEF (cycles) 0.00*
13
Operations - phase fast curve 2
14
Operations - ground fast curve 2
15
Operations to lockout - phase 4
16
Operations to lockout - ground 4
17
Operations to lockout - SEF OFF*
18
Reclose interval 1 (cycles) 300.00
19
Reclose interval 2 (cycles) 600.00
20
Reclose interval 3 (cycles) 600.00
21
Reclose interval 4 (cycles) 0.00*
22
Reset time for auto reclose (cycles) 1800.00
23
Reset time from lockout (cycles) 600.00
24
Close power wait time (cycles) 300.00
25
Complex fast curve - phase (Y/N) N
Const. time adder - phase fast curve (cycles) 0.00*
Vert. multiplier - phase fast curve 1.00*
Min. response - phase fast curve (cycles) 0.00*
26
Complex fast curve - ground (Y/N) N
Const. time adder - ground fast curve (cycles) 0.00*
Vert. multiplier - ground fast curve 1.00*
Min. response - ground fast curve (cycles) 0.00*
27
Complex delay curve - phase (Y/N) N
Const. time adder - phase delay curve (cycles) 0.00*
Vert. multiplier - phase delay curve 1.00*
Min. response - phase delay curve (cycles) 0.00*
28
Complex delay curve - ground (Y/N) N
Const. time adder - ground delay curve (cycles) 0.00*
Vert. multiplier - ground delay curve 1.00*
Min. response - ground delay curve (cycles) 0.00*
