Settings
38 SEL-351P Quick-Start Installation and User's Guide (Portuguese)
No. Settings Groups 1 (Main) and 2 (Alternate) EZ
Settings:
Factory Settings:
29
High current trip - phase (Y/N) N
High current trip - phase (multiple) OFF*
Time delay - phase high current trip (cycles) 0.00*
Activate high current trip - phase OFF*
30
High current trip - ground (Y/N) N
High current trip - ground (multiple) OFF*
Time delay - ground high current trip (cycles) 0.00*
Activate high current trip - ground OFF*
31
High current lockout - phase (Y/N) N
High current lockout - phase (multiple) OFF*
Activate high current lockout - phase OFF*
32
High current lockout - ground (Y/N) N
High current lockout - ground (multiple) OFF*
Activate high current lockout - ground OFF*
33
Cold load pickup scheme (Y/N) N
Cold load pickup - phase (multiple) OFF*
Cold load pickup - ground (multiple) OFF*
Loss of load diversity time (cycles) 0.00*
Restore min. trips - time limit (cycles) OFF*
Restore min. trip - phase (Y/N) N*
Restore min. trip - ground (Y/N) N*
Restore min. trip - SEF (Y/N) N*
34
Sequence coordination (Y/N) N
35
Ground trip precedence (Y/N) N*
36
Underfrequency loadshedding (Y/N) N
Underfrequency pickup (Hz) OFF*
Underfrequency time delay (cycles) 6.00*
37
Demand meter time constant (min.) 5
Global EZ Settings:
38
System Frequency (Hz) 60
39
Phase Rotation ABC
40
Recloser Wear Monitor (AUTO,Y,N) AUTO
Interrupt rating (A pri.) 6000
41
Reset trip-latched LEDs when recloser closes (Y,N) Y
42
True three-phase voltage connected (Y,N) N
43
Battery Amp-hours 8.0
44
% Battery capacity for sleep 20
45
Turn on the 12 V power (Y,N) N
Keep the 12 V power on while asleep (Y,N) N*
46
SF6 low pressure warning threshold (atmospheres) 1.1
*see comments preceding Table 8.
