1-2 Factory-Set Logic Date Code 990430
SEL-351P Manual Técnico
The correlation between EZ recloser control settings and “regular” settings is given in Table
SECTION 1: .1. The correlation between EZ global settings and “regular” global settings is also
given at the end of
Table SECTION 1: .1.
Table SECTION 1: .1: Correspondence Between EZ Settings and “Regular” Settings
EZ Recloser Control Settings
(SHO EZ n command; SET EZ n command)
Corresponding “Regular” Settings
(SHO n command; SET n command)
Control Identifier (30 characters)
Circuit Identifier (30 characters)
RID
TID
CT Ratio
PT Ratio
CTR, CTRN
PTR, PTRS
Min. trip - phase
Min. trip - ground
Min. trip - SEF
51P1P, 51P2P, 50P4P, 50P6P
51G1P, 51G2P, 50G6P, 51N1P, 51N2P, 50N6P
50N3P, 50N4P
Fast curve - phase
Time dial - phase fast curve
EM reset - phase fast curve
51P1C
51P1TD
51P1RS
Fast curve - ground
Time dial - ground fast curve
EM reset - ground fast curve
51G1C
51N1C
51G1TD
51N1TD
51G1RS
51N1RS
Delay curve - phase
Time dial - phase delay curve
EM reset - phase delay curve
51P2C
51P2TD
51P2RS
Delay curve - ground
Time dial - ground delay curve
EM reset - ground delay curve
51G2C
51N2C
51G2TD
51N2TD
51G2RS
51N2RS
Time delay - SEF 67N3D
Operations - phase fast curve
Operations - ground fast curve
Operations to lockout - phase
Operations to lockout - ground
OPPH
OPGR
OPLKPH
OPLKGR
