Table SECTION 10: .6: SEL-351P Recloser Control Relay Word and Its Correspondence
to TAR Command
TAR 0
(Front-Panel
LEDs)
LED10
(EN)
LED11
(AC
SUPPLY)
LED12
(BATTERY
PROBLEM)
LED13
(HOT LINE
TAG)
LED14
(TRIP)
LED15
(FAST
CURVE)
LED16
(HIGH
CURRENT)
LED 17
(81)
TAR 1
(Front-Panel
LEDs)
LED18
(RESET)
LED19
(CYCLE)
LED20
(LOCKOUT)
LED21
(A)
LED22
(B)
LED23
( C )
LED24
(G)
LED25
(SEF)
TAR 2
50A1 50B1 50C1 50A2 50B2 50C2 50A3 50B3
TAR 3
50C3 50A4 50B4 50C4 50AB1 50BC1 50CA1 50AB2
TAR 4
50BC2 50CA2 50AB3 50BC3 50CA3 50AB4 50BC4 50CA4
TAR 5
50A 50B 50C 51P1 51P1T 51P1R 51N1 51N1T
TAR 6
51N1R 51G1 51G1T 51G1R 51P2 51P2T 51P2R 51N2
TAR 7
51N2T 51N2R 51G2 51G2T 51G2R 51Q 51QT 51QR
TAR 8
50P1 50P2 50P3 50P4 50N1 50N2 50N3 50N4
TAR 9
67P1 67P2 67P3 67P4 67N1 67N2 67N3 67N4
TAR 10
67P1T 67P2T 67P3T 67P4T 67N1T 67N2T 67N3T 67N4T
TAR 11
50G1 50G2 50G3 50G4 50Q1 50Q2 50Q3 50Q4
TAR 12
67G1 67G2 67G3 67G4 67Q1 67Q2 67Q3 67Q4
TAR 13
67G1T 67G2T 67G3T 67G4T 67Q1T 67Q2T 67Q3T 67Q4T
TAR 14
50P5 50P6 50N5 50N6 50G5 50G6 50Q5 50Q6
TAR 15
50QF 50QR 50GF 50GR 32VE 32QGE 32NE 32QE
TAR 16
F32P R32P F32Q R32Q F32QG R32QG F32V R32V
TAR 17
F32N R32N 32PF 32PR 32QF 32QR 32GF 32GR
TAR 18
27A1 27B1 27C1 27A2 27B2 27C2 59A1 59B1
TAR 19
59C1 59A2 59B2 59C2 27AB 27BC 27CA 59AB
TAR 20
59BC 59CA 59N1 59N2 59Q 59V1 27S 59S1
TAR 21
59S2 59VP 59VS SF 25A1 25A2 3P27 3P59
TAR 22
81D1 81D2 81D3 81D4 81D5 81D6 27B81 50L
TAR 23
81D1T 81D2T 81D3T 81D4T 81D5T 81D6T VPOLV LOP
TAR 24
50NF 50NR IN106 IN105 IN104 IN103 IN102 IN101
TAR 25
LB1 LB2 LB3 LB4 LB5 LB6 LB7 LB8
TAR 26
RB1 RB2 RB3 RB4 RB5 RB6 RB7 RB8
TAR 27
LT1 LT2 LT3 LT4 LT5 LT6 LT7 LT8
TAR 28
SV1 SV2 SV3 SV4 SV1T SV2T SV3T SV4T
TAR 29
SV5 SV6 SV7 SV8 SV5T SV6T SV7T SV8T
TAR 30
SV9 SV10 SV11 SV12 SV9T SV10T SV11T SV12T
TAR 31
SV13 SV14 SV15 SV16 SV13T SV14T SV15T SV16T
TAR 32
79RS 79CY 79LO SH0 SH1 SH2 SH3 SH4
TAR 33
CLOSE CF RCSF OPTMN RSTMN FSA FSB FSC
TAR 34
BCW 50P32 NOBATT 59VA TRGTR 52A COMMT CHRGG
TAR 35
SG1 SG2 SG3 SG4 SG5 SG6 ZLOUT ZLIN
TAR 36
ZLOAD BCWA BCWB BCWC BCBOK TOSLP DISTST DTFAIL
TAR 37
ALARM OUT107 OUT106 OUT105 OUT104 OUT103 OUT102 OUT101
TAR 38
3PO SOTFE Z3RB KEY EKEY ECTT WFC PT
TAR 39
PTRX2 PTRX PTRX1 UBB1 UBB2 UBB Z3XT DSTRT
TAR 40
NSTRT STOP BTX TRIP OC CC CLG NOMSG
TAR 41
67P2S 67N2S 67G2S 67Q2S PDEM NDEM GDEM QDEM
TAR 42
PB1 PB2 PB3 PB4 PB5 PB6 PB7 PB8
