H-4 Distributed Network Protocol (DNP) V3.00 Date Code 991201
SEL-351P Manual Técnico
Requires Data Link Layer Confirmation:
Never
Always
Sometimes If 'Sometimes', when?
Configurable If 'Configurable', how? by settings.
Requires Application Layer Confirmation:
Never
Always (not recommended)
When reporting Event Data (Slave devices only)
When sending multi-fragment responses (Slave devices only)
Sometimes If 'Sometimes', when?
Configurable If 'Configurable', how?
Timeouts while waiting for:
Data Link Confirm None Fixed at
Variable Configurable
Complete Appl. Fragment None Fixed at
Variable Configurable
Application Confirm None Fixed at
Variable Configurable
Complete Appl. Response None Fixed at
Variable Configurable
Others
Attach explanation if 'Variable' or 'Configurable' was checked for any timeout.
Sends/Executes Control Operations:
WRITE Binary Outputs Never Always Sometimes Configurable
SELECT/OPERATE Never Always Sometimes Configurable
DIRECT OPERATE Never Always Sometimes Configurable
DIRECT OPERATE - NO ACK Never Always Sometimes Configurable
Count > 1 Never Always Sometimes Configurable
Pulse On Never Always Sometimes Configurable
Pulse Off Never Always Sometimes Configurable
Latch On Never Always Sometimes Configurable
Latch Off Never Always Sometimes Configurable
Queue Never Always Sometimes Configurable
Clear Queue Never Always Sometimes Configurable
Attach explanation if 'Sometimes' or 'Configurable' was checked for any operation.
FILL OUT THE FOLLOWING ITEM FOR MASTER DEVICES ONLY:
Expects Binary Input Change Events:
Either time-tagged or non-time-tagged for a single event
Both time-tagged and non-time-tagged for a single event
Configurable (attach explanation)
