Front-Panel Interface
30 SEL-351P Quick-Start Installation and User's Guide (Portuguese)
AJUSTE
Primary
Functions
Corresponding
Serial Port
Command
Access Level
Password for
Front-Panel
Access
Description
SHOW
EZ
FZ
GROUP
GLOBAL
PORT
PASS
SHO EZ
SET FZ
SHO
SHO G
SHO P
PASS
1
1
1
1
1
1
None
None
None
None
None
None
Show EZ settings (group 1 - 6).
Show FZ settings (global EZ settings).
Show GROUP settings (group 1 - 6).
Show GLOBAL settings.
Show PORT settings.
Show passwords.
SET
EZ
FZ
GROUP
GLOBAL
PORT
PASS
SET EZ
SET FZ
SET
SET G
SET P
PASS
E
E
2
2
2
2
Level E
Level E
Level 2
Level 2
Level 2
Level 2
Set EZ settings (group 1 - 6).
Set FZ settings (global EZ settings).
Set GROUP settings (group 1 - 6).
Set GLOBAL settings.
Set PORT settings.
Set passwords.
CNTRL
Primary
Functions
Corresponding
Serial Port
Command
Access Level
Password for
Front-Panel
Access
Description
EXTRA
CONTROL
POSITION
OPERATE
N/A N/A None View position of or operate extra user-
configured switch-type control.
OUTPUT
CONTACT
TEST
PUL
2 Level 2 Pulse output contact (OUT101 - ALARM)
for 1 second.
GRUPO
Primary
Functions
Corresponding
Serial Port
Command
Access Level
Password for
Front-Panel
Access
Description
ACTIVE
GROUP
DISPLAY
CHANGE
GRO
GRO n
1
B
None
Level B
Show active setting group.
Change active setting group to setting
group n.
