9-20 Setting the SEL-351P Recloser Control Date Code 990430
SEL-351P Manual Técnico
Row Relay Word Bits
32
79RS 79CY 79LO SH0 SH1 SH2 SH3 SH4
33
CLOSE CF RCSF OPTMN RSTMN FSA FSB FSC
34
BCW 50P32 NOBATT 59VA TRGTR 52A COMMT CHRGG
35
SG1 SG2 SG3 SG4 SG5 SG6 ZLOUT ZLIN
36
ZLOAD BCWA BCWB BCWC BCBOK TOSLP DISTST DTFAIL
37
ALARM OUT107 OUT106 OUT105 OUT104 OUT103 OUT102 OUT101
38
3PO SOTFE Z3RB KEY EKEY ECTT WFC PT
39
PTRX2 PTRX PTRX1 UBB1 UBB2 UBB Z3XT DSTRT
40
NSTRT STOP BTX TRIP OC CC CLG NOMSG
41
67P2S 67N2S 67G2S 67Q2S PDEM NDEM GDEM QDEM
42
PB1 PB2 PB3 PB4 PB5 PB6 PB7 PB8
43
PB9 32NF 32NR * WBTRT SF6LO DISCHG LED9
44
LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8
45
OCP OCG OLP OLG OLS HTP HTG HLP
46
HLG CLP RPP RPG RPS SEQC 3PHV GTP
47
1
RMB8A RMB7A RMB6A RMB5A RMB4A RMB3A RMB2A RMB1A
48
1
TMB8A TMB7A TMB6A TMB5A TMB4A TMB3A TMB2A TMB1A
49
1
RMB8B RMB7B RMB6B RMB5B RMB4B RMB3B RMB2B RMB1B
50
1
TMB8B TMB7B TMB6B TMB5B TMB4B TMB3B TMB2B TMB1B
51
1
LBOKB CBADB RBADB ROKB LBOKA CBADA RBADA ROKA
52
* * * * * * * *
53
* * * * * * * *
54
* * * * * * * *
55
* * * * * * * *
56
RAW52B RAW52A WB52A WBBRK WBCL WBTR CLCAP TRCAP
1. M
IRRORED
B
ITS
™ elements only valid in firmware versions 1 or greater.
Table SECTION 9: .4: Relay Word Bit Definitions for SEL-351P Recloser Control
Row
Bit
Definition
Primary
Application
2 50A1 Level 1 A-phase instantaneous overcurrent element
(A-phase current above pickup setting 50P1P; see
Figure 3.1)
Tripping,
Control
50B1 Level 1 B-phase instantaneous overcurrent element
(B-phase current above pickup setting 50P1P; see
Figure 3.1)
50C1 Level 1 C-phase instantaneous overcurrent element
(C-phase current above pickup setting 50P1P; see
Figure 3.1)
