9-40 Setting the SEL-351P Recloser Control Date Code 990430
SEL-351P Manual Técnico
Row
Bit
Definition
Primary
Application
LED4 Alternate Settings LED (see Figure 1.35)
LED5 Lock LED (see Figure 1.35)
LED6 Aux. 1 LED (see Figure 1.36)
LED7 Aux. 2 LED (see Figure 1.36)
LED8 Recloser Closed LED (see Figure 1.36)
45 OCP Operations - phase fast curve (see Figure 1.6) Control
OCG Operations - ground fast curve (see Figure 1.7)
OLP Operations to lockout - phase (see Figure 1.8)
OLG Operations to lockout - ground (see Figure 1.9)
OLS Operations to lockout - Sensitive earth fault (see
Figure 1.10)
HTP High current trip - phase (see Figure 1.11)
HTG High current trip - ground (see Figure 1.12)
HLP High current lockout - phase (see Figure 1.13)
46 HLG High current lockout - ground (see Figure 1.14)
CLP Phase cold load pickup scheme enabled (see
Figure 1.2
RPP Restore pickup - phase (see Figures 1.1 and 1.2)
RPG Restore pickup - ground (see Figures 1.1 and 1.3)
RPS Restore pickup - Sensitive earth fault (see Figure 1.1
and Figure 1.4)
SEQC Sequence coordination enabled (see Figure 1.27)
3PHV Three phase voltage hooked up to control (see
Figure 4.1)
GTP Ground trip precedence enabled (see Figure 1.24)
