9-42 Setting the SEL-351P Recloser Control Date Code 990430
SEL-351P Manual Técnico
Row
Bit
Definition
Primary
Application
TMB3B Channel B, transmit bit 3
TMB2B Channel B, transmit bit 2
TMB1B Channel B, transmit bit 1
51 LBOKB Channel B, looped back ok
CBADB Channel B, channel unavailablity over threshold
RBADB Channel B, outage duration over threshold
ROKB Channel B, received data ok
LBOKA Channel A, looped back ok
CBADA Channel A, channel unavailablity over threshold
RBADA Channel A, outage duration over threshold
ROKA Channel A, received data ok
52 * Reserved for future use.
53 * Reserved for future use.
54 * Reserved for future use.
55 * Reserved for future use.
56 RAW52B 52b breaker auxiliary status – not time-qualified (see
Figure 7.29)
Testing
RAW52A 52a breaker auxiliary status – not time-qualified (see
Figure 7.29)
WB52A Breaker status – time-qualified (see Figure 7.29) Breaker status
WBBRK Break output contact (form b; see Figure 7.29) Testing
WBCL Close output contact (form c; see Figure 7.29)
WBTR Trip output contact (form c; see Figure 7.29)
CLCAP Close capacitor charged higher than 20 Vdc (see
Figure 7.29)
Closing, Control
TRCAP Trip capacitor charged higher than 80 Vdc (see
Figure 7.29)
Tripping,
Closing, Control
** IMPORTANT: See Appendix F: Setting Negative-Sequence Overcurrent Elements for
special instructions on setting negative-sequence overcurrent elements.
