S
ETTINGS
S
HEET Page
5
of 23
F
OR THE
SEL-351P R
ECLOSER
C
ONTROL Date
G
ROUP
S
ETTINGS
(S
ERIAL
P
ORT
C
OMMAND
SET
AND
F
RONT
P
ANEL
)
Date Code 990215
Electromechanical Reset (Y,N; applicable only to curves U1-U5, C1-C5) 51P2RS =
Constant time adder (0.00-60.00 cyc.) 51P2CT =
Minimum response (0.00-60.00 cyc.) 51P2MR =
Neutral Ground Time-Overcurrent Elements - Channel IN (see Figure 3.16 and 3.17)
(Make the following settings if preceding enable setting E51N = 1 or 2)
Pickup (OFF, 0.005-0.160 A) 51N1P =
Curve (U1-U5, C1-C5, recloser or user curve; see Figures 9.1 through
9.20)
51N1C =
Time-Dial (0.50-15.00 for curves U1-U5, 0.05-1.00 for curves C1-C5,
0.10-2.00 for recloser and user curves)
51N1TD =
Electromechanical Reset (Y,N; applicable only to curves U1-U5, C1-C5) 51N1RS =
Constant time adder (0.00-60.00 cyc.) 51N1CT =
Minimum response (0.00-60.00 cyc.) 51N1MR =
(Make the following settings if preceding enable setting E51N = 2)
Pickup (OFF, 0.005-0.160 A) 51N2P =
Curve (U1-U5, C1-C5, recloser or user curve; see Figures 9.1 through
9.20)
51N2C =
Time-Dial (0.50-15.00 for curves U1-U5, 0.05-1.00 for curves C1-C5,
0.10-2.00 for recloser and user curves)
51N2TD =
Electromechanical Reset (Y,N; applicable only to curves U1-U5, C1-C5) 51N2RS =
Constant time adder (0.00-60.00 cyc.) 51N2CT=
Minimum response (0.00-60.00 cyc.) 51N2MR=
Residual Ground Time-Overcurrent Elements (see Figure 3.18 and Figure 3.19)
(Make the following settings if preceding enable setting E51G = 1 or 2)
Pickup (OFF, 0.10-3.20 A) 51G1P =
Curve (U1-U5, C1-C5, recloser or user curve; see Figures 9.1 through
9.20)
51G1C =
Time-Dial (0.50-15.00 for curves U1-U5, 0.05-1.00 for curves C1-C5,
0.10-2.00 for recloser and user curves)
51G1TD =
Electromechanical Reset (Y,N; applicable only to curves U1-U5, C1-C5) 51G1RS =
Constant time adder (0.00-60.00 cyc.) 51G1CT =
Minimum response (0.00-60.00 cyc.) 51G1MR =
(Make the following settings if preceding enable setting E51G = 2)
Pickup (OFF, 0.10-3.20 A) 51G2P =
Curve (U1-U5, C1-C5, recloser or user curve; see Figures 9.1 through
9.20)
51G2C =
