S
ETTINGS
S
HEET Page
7
of 23
F
OR THE
SEL-351P R
ECLOSER
C
ONTROL Date
G
ROUP
S
ETTINGS
(S
ERIAL
P
ORT
C
OMMAND
SET
AND
F
RONT
P
ANEL
)
Date Code 990215
Phase directional element 3-phase current pickup (0.10-2.00 A) 50P32P =
(Make settings Z2F, Z2R, 50QFP, 50QRP, a2 and k2 if preceding enable
setting E32 = Y. If E32 = AUTO, these settings are made automatically)
Forward directional Z2 threshold (-320.00 to +320.00 Ω secondary)
Z2F =
Reverse directional Z2 threshold (-320.00 to +320.00 Ω secondary)
Z2R =
Forward directional negative-sequence current pickup
(0.05-1.00 A)
50QFP =
Reverse directional negative-sequence current pickup
(0.05-1.00 A)
50QRP =
Positive-sequence current restraint factor, I2/I1 (0.02-0.50, unitless) a2 =
Zero-sequence current restraint factor, I2/I0 (0.10-1.20, unitless) k2 =
(Make settings 50GFP, 50GRP, a0, Z0F, and Z0R if preceding enable
setting E32 = Y and preceding setting ORDER contains V. If E32 =
AUTO and ORDER contains V, these settings are made automatically.)
Forward directional residual ground pickup (0.05-1.00 A) 50GFP =
Reverse directional residual ground pickup (0.05-1.00 A) 50GRP =
Positive-sequence current restraint factor, I0/I1 (0.02-0.50, unitless) a0 =
Forward directional Z0 threshold (-320.00 to +320.00 Ω secondary)
Z0F =
Reverse directional Z0 threshold (-320.00 to +320.00 Ω secondary)
Z0R =
Voltage Elements (see Figures 3.21, 3.22, and 3.23)
(Make the following settings if preceding enable setting EVOLT = Y)
Phase undervoltage pickup (OFF, 0.0-150.0 V secondary) 27P1P =
Phase undervoltage pickup (OFF, 0.0-150.0 V secondary) 27P2P =
Phase overvoltage pickup (OFF, 0.0-150.0 V secondary) 59P1P =
Phase overvoltage pickup (OFF, 0.0-150.0 V secondary) 59P2P =
Zero-sequence (3V0) overvoltage pickup (OFF, 0.0-150.0 V secondary) 59N1P =
Zero-sequence (3V0) overvoltage pickup (OFF, 0.0-150.0 V secondary) 59N2P =
Negative-sequence (V2) overvoltage pickup (OFF, 0.0-100.0 V
secondary)
59QP =
Positive-sequence (V1) overvoltage pickup (OFF, 0.0-150.0 V
secondary)
59V1P =
Channel VS undervoltage pickup (OFF, 0.0-150.0 V secondary) 27SP =
Channel VS overvoltage pickup (OFF, 0.0-150.0 V secondary) 59S1P =
Channel VS overvoltage pickup (OFF, 0.0-150.0 V secondary) 59S2P =
Phase-to-phase undervoltage pickup (OFF, 0.0-260.0 V secondary) 27PP =
Phase-to-phase overvoltage pickup (OFF, 0.0-260.0 V secondary) 59PP =
