S
ETTINGS
S
HEET Page
11
of 23
F
OR THE
SEL-351P R
ECLOSER
C
ONTROL Date
G
ROUP
S
ETTINGS
(S
ERIAL
P
ORT
C
OMMAND
SET
AND
F
RONT
P
ANEL
)
Date Code 990215
SV6 Pickup Time (0-999999.00 cycles in 0.25-cycle steps) SV6PU =
SV6 Dropout Time (0-999999.00 cycles in 0.25-cycle steps) SV6DO =
SV7 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV7PU =
SV7 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV7DO =
SV8 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV8PU =
SV8 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV8DO =
SV9 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV9PU =
SV9 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV9DO =
SV10 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV10PU =
SV10 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV10DO =
SV11 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV11PU =
SV11 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV11DO =
SV12 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV12PU =
SV12 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV12DO =
SV13 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV13PU =
SV13 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV13DO =
SV14 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV14PU =
SV14 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV14DO =
SV15 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV15PU =
SV15 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV15DO =
SV16 Pickup Time (0-16000.00 cycles in 0.25-cycle steps) SV16PU =
SV16 Dropout Time (0-16000.00 cycles in 0.25-cycle steps) SV16DO =
Recloser Control Logic Enable Settings (see Section 1)
Operations - phase fast curve (OFF, 1-5) OPPH =
Operations - ground fast curve (OFF, 1-5) OPGR =
Operations to lockout - phase (OFF, 1-5) OPLKPH =
Operations to lockout - ground (OFF, 1-5) OPLKGR =
Operations to lockout - SEF (OFF, 1-5) OPLKSF =
Activate high current trip - phase (OFF, 1-5) HITRPH =
Activate high current trip - ground (OFF, 1-5) HITRGR =
Activate high current lockout - phase (OFF, 1-5) HILKPH =
Activate high current lockout - ground (OFF, 1-5) HILKGR =
Cold load pickup scheme - phase (Y,N) ECOLDP =
Cold load pickup scheme - ground (Y,N) ECOLDG =
Restore min. trip - phase (Y,N) RPPH =
Restore min. trip - ground (Y,N) RPGR =
