Date Code 990430 Serial Port Communications and Commands 10-13
SEL-351P Manual Técnico
Access
Level
Prompt
Serial Port
Command
Command Description
Corresponding
Front-Panel
Pushbutton
1 => TAR Display recloser control element
status
OTHER
1 => TIM View/change time OTHER
1 => TRI Trigger an event report
E =+> BTT Display latest battery discharge test
results and time remaining until next
discharge test
E =+> BTT NOW Force battery discharge test OTHER
E =+> SET EZ Change EZ group settings SET
E =+> SET FZ Change EZ global settings SET
B ==> BRE n Preload/reset breaker/recloser wear
and trip operation counters
OTHER
B ==> CLO Close breaker/recloser CLOSE
B ==> GRO n Change active setting group GROUP
B ==> OPE Open breaker/recloser TRIP
B ==> PUL Pulse output contact CNTRL
2 =>> CON Control remote bit
2 =>> COP Copy setting group
2 =>> LOO M
IRRORED
B
ITS
loopback
2 =>> PAS View/change passwords SET
2 =>> SET Change group settings SET
2 =>> SET L Change logic settings
2 =>> SET G Change global settings SET
2 =>> SET R Change sequence of event triggering
settings
2 =>> SET P Change serial port settings SET
2 =>> SET T Change text label settings
2 =>> STA C Clear Status Report
2 =>> VER Show version information
The recloser control responds with “Invalid Access Level” if a command is entered from an
access level lower than the specified access level for the command. If the command you entered
does not match any of the commands in the SEL-351P command set shown in Table 10.5, the
control responds:
Invalid Command
Many of the command responses display the following header at the beginning:
RECLOSER R1 Date: 03/05/97 Time: 17:03:26.484
FEEDER 2101
