Date Code 990430 SEL-351P Command Summary Page 3 of 3
SEL-351P Manual Técnico
Access
Level B
Commands
Access Level B commands primarily allow you to operate control parameters and output contacts.
All Access Level 1 and Access Level E commands can also be executed from Access Level B.
The screen prompt is: ==>
BRE n Enter BRE W A to preload breaker/recloser contact wear and trip operation counters. Enter
BRE R to reset breaker/recloser monitor data.
CLO Close the recloser or circuit breaker.
GRO n Change active settings group to settings group n (n = 1-6).
OPE Open the recloser or circuit breaker.
PUL n k Pulse output contact n (OUT101 - OUT107, ALARM) for k (1-30) seconds. Parameter n must be
specified; k defaults to 1 if not specified.
Access
Level 2
Commands
Access Level 2 commands allow unlimited access to control settings, parameters, and output
contacts. All Access Level 1, Access Level E, and Access Level B commands are available from
Access Level 2. The screen prompt is: =>>
CON n Control Relay Word bit RBn (Remote Bit n; n = 1 through 8). Execute CON n and the control
responds: CONTROL RBn. Then reply with one of the following:
SRB n set Remote Bit n (assert RBn).
CRB n clear Remote Bit n (deassert RBn).
PRB n pulse Remote Bit n [assert RBn for 1/4 cycle].
COP m n Copy settings and logic equations from settings group m to settings group n.
LOO Set M
IRRORED BITS port to loopback.
PAS Show existing Access Level 1, E (EZ), B, and 2 passwords.
PAS 1 xxxxxx Change Access Level 1 password to xxxxxx.
PAS E xxxxxx Change Access Level E (EZ) password to xxxxxx
PAS B xxxxxx Change Access Level B password to xxxxxx.
PAS 2 xxxxxx Change Access Level 2 password to xxxxxx.
SET n Change “regular” settings for settings group n ( n = 1-6).
SET G Change global settings.
SET L n Change SEL
OGIC
®
Control Equation settings for settings group n ( n = 1-6).
SET P n Change port settings for port n (n = 1, 2, 3, F).
SET R Change Sequential Events Recorder (SER) settings.
SET T Change text label settings for front-panel display and and extra local control.
STA C Clears status warning or failure and reboots recloser control.
VER Show firmware version and options
Key Stroke
Commands
Cntrl - Q Send XON command to restart communication port output previously halted by XOFF.
Cntrl - S Send XOFF command to pause communication port output.
Cntrl - X Send CANCEL command to abort current command and return to current access level prompt.
